Product Description
Suitable for computer CPU cooling,GPU,VGA,CHIP,industrial frequency conversion driver, laser head cooling, tram, electric motorcycle, beauty, air conditioning evaporator and industrial control cabinet cooling
Specification:
Brand Name:COOLTEX
Material:Aluminum
Colour: Black
Role: heat dissipation, heat transfer
The sealing process: vacuum aluminum brazing,Parts brazing seal as a whole
80mm radiator
Size:104(D) x 82(W) x 25(H)mm
Can be installed 80mm cooling fan,mounting hole size:71.5×71.5mm
Nozzle: 9.5mm ,Can use for Inner dia 7-8mm water cooling pipe
System features: pure aluminum fins, 1 inch 17 – 20 fin
Fin density:8 lines per inch
Net weight:85g
90mm radiator
Size:125(D) x 92(W) x 30(H)mm
Can be installed 92mm cooling fan,mounting hole size:82.5×82.5mm
Nozzle: 9.5mm,Can use for Inner dia 7mm-8mm water cooling pipe
System features: pure aluminum fins, 1 inch 17 – 20 fin
Fin density:10 lines per inch
Net weight:160g
120mm radiator
Size:155(D) x 120(W) x 33(H)mm
Can be installed 120mm cooling fan,mounting hole size:105x105mm
Nozzle: 11mm,Can use for Inner dia 8mm-10mm water cooling pipe
System features: pure aluminum fins, 1 inch 17 – 20 fin
Fin density:18 lines per inch
Net weight:220g
240mm radiator
Size:275(D) x 120(W) x 32(H)mm
Can be installed 2pcs x 120mm fan,mounting hole size: 105x105mm
Nozzle: 11(D) MM ,Can use for Inner dia 8mm-10mm water cooling pipe
System features: pure aluminum fins, 1 inch 17 – 20 fin
Fin density:18 lines per inch
Net weight:385g
280mm radiator
Size:310(D) x 140(W) x 30(H)mm
Can be installed 2pcs x 120mm fan or 2pcs x 140mm,mounting hole size:105x105mm and 125x125mm
Nozzle: 11mm,Can use for Inner dia 8mm-10mm water cooling pipe
System features: pure aluminum fins, 1 inch 17 – 20 fin
Fin density:15 lines per inch
Net weight:510g
Packing List:
- Water Cooled Radiator * 1
Screw * 1bag
Note:
The water discharge screw should not be installed on the water line surface
Otherwise, the top cover will cause the leaking screw to wear out
