GENERAL SPECIFICATIONS
ITEM
|
VALUE
|
Step Angle | 1.8 ° |
Step Angle Accuracy | ±5% (full step, no load) |
Resistance Accuracy | ±10% |
Inductance Accuracy | ±20% |
Temperature Rise | 80 °C Max.(rated current, 2 phase on) |
Ambient Temperature | -20 °C – +50 °C |
Insulation Resistance | 100 MO Min., 500VDC |
Dielectric Strength | 820VAC, 1s, 3mA |
Shaft Radial Play | 0.02 Max. (450 g-load) |
Shaft Axial Play | 0.08 Max. (450 g-load) |
Max. Radial Force | 220 N (20 mm from the flange) |
Max. Axial Force | 60 N |
